The DKT300 11-18 Phase Control Thyristor is a compact yet high-performance component ideal for industrial power control applications. With its center amplifying gate and durable metal case with ceramic insulation, the DKT300 ensures efficient switching with low on-state voltage drop and minimal switching losses. It can handle up to 300A of average on-state current and 4.65kA of surge current. This thyristor is designed for use in AC controllers, DC and AC motor control, and controlled rectifiers, providing reliable performance in demanding environments.
Features
Center amplifying gate design for efficient switching
Metal case with ceramic insulator for enhanced durability and insulation
Low on-state voltage drop and switching losses for higher efficiency
Surge current capability up to 4.65kA
Voltage range: 1100V to 1800V
High current capacity: 300A average on-state current
Excellent thermal performance with a thermal resistance of max. 0.08°C/W
Compact design (weight: 60g)
Wide operating temperature range: -40°C to 140°C
Applications
AC Controllers: Regulates alternating current in industrial systems.
DC and AC Motor Control: Controls motors in industrial applications.
Controlled Rectifiers: Used in systems that convert AC to DC power efficiently.
Power Systems: Ideal for efficient energy conversion and regulation in industrial systems.
Surge Protection: Can handle high surge currents, ensuring protection in electrical systems.
